The DVB RF Analyser provides analog and digital TV monitoring.
Request a DemoThe DVB RF Analyser provides analog and digital TV monitoring. This allows real-time analysis and monitoring of MPEG Transport Streams via TS-ASI input & RF output. Featuring TR101 290 3-level monitoring, it lists PSI/SI and transport stream program information, and details of all programs running in a TV network or a transponder. 128GB of storage – with optional SSD add-on – saves hours of TS footage for instant replay and analysis.
The DVB RF Analyser provides analog and digital TV monitoring. This allows real-time analysis and monitoring of MPEG Transport Streams via TS-ASI input & RF output. Featuring TR101 290 3-level monitoring, it lists PSI/SI and transport stream program information, and details of all programs running in a TV network or a transponder. 128GB of storage – with optional SSD add-on – saves hours of TS footage for instant replay and analysis.
⦁ All-in-one Digital TV Analyzer
⦁ DVB-C modulation.
⦁ Compatible with 4K, 1080p, 720p, and 576i.
⦁ Supports DVB-CI and BISS 1/E.
⦁ Transport Stream Analysis: RF, ASI, and IP input.
⦁ Real-Time Decoder - Displays real-time TV feed (through CA system), including program names& numbers, provider information, and video & audio PIDs.
⦁ TR 101 290 Priority 1 / 2 / 3 real-time monitoring, not including buffer home related parameters.
⦁ Base Information - Counts PID % according to stream type. Video, audio, PSI/SI, and null packages.
⦁ PID List - Displays all PIDs in the current stream.
⦁ Program Information - Displays detailed information on unencrypted programs, including video resolution and audio compression rate.
⦁ PCR Monitoring - Calculates PCR interval and PCR accuracy.
⦁ PSI/SI List - Displays PSI/SI information in tree format. Includes PAT, PMT, and CAT. (NIT, SDT, RST, TDT, EIT by option only).
⦁ PID Capture - Captures a specific PID by type: video, audio, PSI (PAT, PMT, NIT, TDT, RST, SDT, EIT, etc.). Displays in HEX format.
⦁ TS Record & Replay - SSD for transport stream recording.
HEVC/H.265
MPEG-4 (AVC/H.264)
MPEG-2
HE AAC v.1 and v.2
AAC LC
MPEG-1/2
MPEG-2 TS (SPTS or MPTS)
Ethernet IP
SDI/HD-SDI
DVB-ASI
HDMI
DVB-T/T2
DVB-C/C2
HLS
RTP
UDP
RTSP
SSE-enhanced CPU (Intel® Core i3, i5, i7 Processor)
8 GB RAM
Any VGA card
